如果我们自己有网站的话我们一定不希望有人恶意的疯狂请求数据,这会给网站带来压力,同时浪费咱们的流量(穷人.jpg)。这时就需要运用Nginx的限制请求频率功能了。
限制分类
Nginx限制请求共有两种模式:
连接频率限制:ngx_http_limit_conn_module | |
请求频率限制:ngx_http_limit_req_module |
注意:需要知道的是一次请求和一次连接是不同的,一次连接要经历多次请求(TCP的一次连接需要经历三次握手请求),连接上后如果不断开则可以一直发送请求。
HTTP协议版本 | 连接关系 |
http 1.0 | 默认一次tcp连接进行一次http请求之后就会断开(由于资源浪费,有些服务器支持通过配置支持多次) |
http 1.1 | 请求头配置:Connection:keep-alive = true,只要tcp连接不断开(默认2小时),一直可以进行http请求,但是一个tcp连接同一时间只支持一个http请求 Connection:keep-alive = false,只能发一次http请求 |
http 2.0 | 多路复用技术Multiplexing,一个tcp可以并发多个http请求(理论无上限,但是一般浏览器会有tcp并发数的限制) |
连接限制
Nginx的ngx_http_limit_conn_module
模块用于限制每个已定义的key的连接数,特别是来自单个IP地址的连接数。并非所有连接都被计数。仅当具有服务器正在处理的请求并且已经读取了整个请求标头时,才对连接进行计数。
配置格式
语法: limit_conn_zone key zone=name:size;
默认: —
上下文: http
语法: limit_conn zone number;
默认: —
上下文: http, server, location
- key: 根据什么进行限制,比如IP($binary_remote_addr)。
- name: zone的名字,随意指定
- size: 我们需要对连接进行计数,那么就需要空间存储,该值设置存储空间大小
示例
limit_conn_zone $binary_remote_addr zone=myname:1m;
server {
location / {
limit_conn myname 1;
}
}
以上配置了一个针对IP的连接限制,zone名称为myname,空间为1m,将其配置在了/
下,限制连接限制为1。
我们可以使用压测工具来进行测试,这里使用的是ab
【了解ab】。使用命令ab -n 50 -c 20 http://server/index.html
。测试报告如下所示:
This is ApacheBench, Version 2.3 <$Revision: 1430300 $>
Copyright 1996 Adam Twiss, Zeus Technology Ltd, http://www.zeustech.net/
Licensed to The Apache Software Foundation, http://www.apache.org/
Benchmarking 123.56.45.209 (be patient).....done
Server Software: nginx/1.16.1
Server Hostname: 123.56.45.209
Server Port: 80
Document Path: /index.html
Document Length: 12 bytes
Concurrency Level: 20
Time taken for tests: 0.168 seconds
Complete requests: 50
Failed requests: 49
(Connect: 0, Receive: 0, Length: 49, Exceptions: 0)
Write errors: 0
Non-2xx responses: 49
Total transferred: 34872 bytes
HTML transferred: 24218 bytes
Requests per second: 298.00 [#/sec] (mean)
Time per request: 67.115 [ms] (mean)
Time per request: 3.356 [ms] (mean, across all concurrent requests)
Transfer rate: 202.96 [Kbytes/sec] received
Connection Times (ms)
min mean[+/-sd] median max
Connect: 20 21 0.5 21 22
Processing: 20 21 0.5 21 22
Waiting: 20 21 0.5 21 22
Total: 40 42 1.0 42 44
根据Complete requests:50
和Failed requests:49
可知连接限制配置成功。查看nginx错误日志:
2020/06/16 18:00:29 [error] 21051#21051: *8111 limiting requests, excess: 0.876 by zone "req_zone", client: 202.200.201.7, server: localhost, request: "GET /index.html HTTP/1.0", host: "xxx"
2020/06/16 18:00:29 [error] 21051#21051: *8112 limiting requests, excess: 0.876 by zone "req_zone", client: 202.200.201.7, server: localhost, request: "GET /index.html HTTP/1.0", host: "xxx"
2020/06/16 18:00:29 [error] 21051#21051: *8114 limiting requests, excess: 0.875 by zone "req_zone", client: 202.200.201.7, server: localhost, request: "GET /index.html HTTP/1.0", host: "xxx"
请求限制
Nginx的ngx_http_limit_req_module
模块用于限制每一个定义的的请求的处理速率,特别是从一个单一的IP地址的请求的处理速率。使用"漏斗"方法完成限制。
配置格式
语法: limit_req_zone key zone=name:size rate=rate;
默认: —
上下文: http
语法: limit_req zone=name [burst=number] [nodelay];
默认: —
上下文: http, server, location
- delay参数指定一个限制,在该限制下,过多的请求将被延迟。默认值为零,即所有多余的请求都会延迟。
示例
limit_req_zone $binary_remote_addr zone=req_zone:1m rate=1r/s;
server {
location / {
limit_req zone=req_zone burst=3 nodelay;
}
}
